P0313 Code: Diagnose Misfire Detected With Low Fuel
P0313: Preserve the Low-Fuel Misfire Event
Confirm fuel level and misfire pattern, then separate fuel starvation from ignition, injector, air, and mechanical causes.
DIAGNOSTIC FOCUS
- FAULT TYPE
- a misfire event recognized while the controller considered fuel level low
- FIRST CHECKS
- Exact component identity, loaded electrical integrity, fuel level, misfire counters, fuel pressure, trims, load, engine speed and voltage, and companion-code order
Low fuel is diagnostic context, not a guaranteed cause; a separate ignition, injector, air, or mechanical fault can still be present.
P0313 means Misfire Detected With Low Fuel. The controller recognized crankshaft-speed variation consistent with misfire while the fuel-level input or strategy indicated a low-fuel condition.
Save the cylinder pattern and pressure evidence before adding fuel, clearing counters, or replacing ignition parts; those actions can change the failed state. Save the complete scan and freeze-frame record before clearing anything, then use the exact VIN service information to identify the monitored circuit and approved test points.
What Does the P0313 Code Mean?
P0313 is the diagnostic label for Misfire Detected With Low Fuel. Misfire monitors infer uneven combustion from crankshaft acceleration and other application-specific inputs rather than watching the flame inside a cylinder. It is a monitor result, not a parts order, and it does not by itself prove the tank ran dry, the pump is weak, or an ignition component is defective.
Low fuel can expose pickup starvation, aeration, or pressure loss on some vehicles, especially with movement or grade, but the code can coexist with an unrelated misfire. The useful distinction is between fuel starvation related to level or vehicle motion, inaccurate level information, and a conventional cylinder-specific or random misfire. That distinction determines whether the next test belongs at a connector, a power or ground path, a control signal, a hydraulic or mechanical system, or an operating-condition check.
Cylinder counters, pressure under the failed condition, trims, fuel level, load, vehicle attitude, and companion ignition or injector codes are stronger evidence than a guess based on tank level alone. A scan tool cannot replace the current wiring diagram, connector view, service precautions, and approved test method. Do not import limits or component locations from another model year.
Capture confirmed, pending and history codes, freeze frame, first-failure order, system voltage, and the conditions present when P0313 set.
Identify tank layout, pickup/module, transfer or saddle-tank strategy, fuel-level senders, pressure-control system, cylinder numbering, and misfire monitor conditions.
Compare the misfire pattern with fuel level and pressure during safe, controlled conditions; then use ignition, injector, air-leak, compression, and mechanical tests where the pattern leads.
P0313 Symptoms, Severity, and Driving Safety
A severe misfire can flash the warning; an intermittent event may stay pending.
One or more cylinders may contribute unevenly.
Fuel pickup loss may appear during turns or grades.
Low supply or ignition faults may extend cranking.
The controller may reduce fuel to a misfiring cylinder.
The symptom may disappear, but the cause still needs proof.
Treat P0313 by current severity. A flashing MIL, fuel leakage, repeated stall, or power loss creates catalyst, fire, and traffic risks.
P0313 Causes and the Evidence That Separates Them
A sound P0313 diagnosis must fit the stored conditions and companion codes. Low level can be causal, coincidental, or incorrectly reported, so preserve the event before refueling and then compare the cylinder and pressure patterns.
Fuel Pickup Starvation or Aeration
Low fuel can uncover a pickup or allow air into the supply under movement.
How to prove it: Compare pressure and misfire occurrence with level, turns, grades, and load using a safe OEM procedure.
Check firstWeak Pump or Restricted Supply
A marginal pump, filter, module, or electrical feed may fail first when conditions are unfavorable.
How to prove it: Measure pressure/volume and loaded pump supply under the failed condition rather than only at idle.
Check firstInaccurate Fuel-Level Information
Sender, wiring, tank shape, transfer pump, or instrument calculations may misstate usable fuel.
How to prove it: Compare sender data and tank/service information; do not assume the displayed gauge is exact.
Verify directlyIgnition Fault
A plug, coil, boot, or control circuit can misfire regardless of fuel level.
How to prove it: Use cylinder-specific swap or electrical tests only when the OEM procedure permits and track whether the misfire follows.
Verify directlyInjector, Air, or Fuel-Trim Fault
An injector imbalance or unmetered air can create a lean cylinder or bank.
How to prove it: Use contribution, balance, trim, leak, and pressure evidence before selecting parts.
Verify directlyCompression or Mechanical Fault
Valve, timing, sealing, or rotating-mechanical problems can produce persistent misfire.
How to prove it: Perform the specified relative compression, leak-down, timing, or mechanical inspection after electrical/fuel basics.
Final branchA successful refuel is evidence of a condition change, not automatic proof that the pump, gauge, or pickup was the root cause. Test the failed state when possible, document the result, and replace a part only after measured evidence supports it.
Using MA500 as an Electrical Baseline for P0313
The iCARZONE MA500 12V/24V Battery & Charging System Tester with SOH/SOC checks battery SOH/SOC, internal resistance, ripple, cranking, and 12V/24V charging. Use it only to document supply stability during P0313 diagnosis.
MA500 does not read or clear engine fault codes. It provides no freeze frame, ECU live data, or actuator commands. Use separate scan equipment and VIN-specific service information.
Fuel-pressure and injector tests require rated equipment, ventilation, and depressurization; rotating-engine and ignition tests require secure leads and shock precautions. Its battery results cannot identify the low-fuel misfire diagnostic path or replace the specified loaded test.
iCARZONE MA500 12V/24V Battery & Charging System Tester with SOH/SOC
Use MA500 only to document the battery, cranking and charging baseline. A separate scan tool and OEM procedure are required to read P0313, capture misfire counters, fuel level, pressure, trims, load, engine speed, voltage and first-failure order, and prove the fault.
Checked September 4, 2026: the public page showed $32.99 USD, no compare-at price, and available status. Recheck the offer, stock, and compatibility.
How to Diagnose P0313 in 6 Evidence-Based Steps
Use this order to preserve the event and avoid parts guesses. Preserve the low-fuel condition if it is safe; if it is not safe, record it completely before adding fuel and note exactly what changed. Let each result choose the next OEM test.
P0313 Quick Diagnostic Path
-
1
Save the Complete Event
- Record code status, freeze frame, fuel level, misfire counters, fuel pressure, trims, load, engine speed and voltage, voltage, and first-failure order.
- Note companion supply, reference, communication, or performance faults.
-
2
Confirm the Exact Hardware
- Use the VIN to identify low-fuel misfire diagnostic path, its controller, connectors, shared paths, and enable conditions.
- Do not borrow terminals, limits, or locations from another application.
-
3
Inspect the Accessible Path
- Safely inspect locks, seals, corrosion, routing, heat or fluid exposure, grounds, and prior repairs.
- Preserve the failed state; do not pierce seals or spread terminals.
-
4
Compare Command and Result
- Observe fuel level, misfire counters, fuel pressure, trims, load, engine speed and voltage during a safe reproduction of the low-fuel operating condition stored with the misfire.
- Scan data narrows the branch but does not replace the specified physical test.
-
5
Test the Leading Branch
- Follow the OEM order for loaded power, ground, signal, control, continuity, isolation, and system tests.
- Record each result and prove external wiring before parts.
-
6
Repair and Verify
- Correct only the proven circuit, component, mechanical, or applicable calibration fault.
- Restore all disturbed items, run the specified monitor, and rescan.
How to Fix P0313 and Verify the Repair
Correct Low-Fuel Supply Cause
Refuel safely and repair a proven pickup, transfer, pump, restriction, or module fault.
Repair Fuel-Level Reporting
Correct a sender, wiring, transfer, or calibration issue only when the level test fails.
Repair the Proven Misfire Cause
Service the specific ignition, injector, air, or mechanical branch supported by cylinder evidence.
Restore Electrical Stability
Repair a verified battery, charging, ground, or module-supply problem that disturbed monitoring or delivery.
Evidence Capture and Mapping
VIN-specific quoteDiagnosis begins with a complete scan, exact hardware identification, and the current service procedure.
Connector or Harness Repair
VIN-specific quoteAccess, sealed terminals, corrosion, heat damage, and shared splices determine labor.
Component Replacement
VIN-specific quoteParts cost alone is incomplete; access, seals, fluids, setup, and relearn can matter.
Controller or Complex System Work
VIN-specific quoteProgramming, network, internal mechanical, or high-risk procedures need separate proof and estimating.
Record the proven fault and repair. Confirm stable fuel pressure, plausible level data, normal cylinder contribution, no flashing MIL, and no returning P0313 or companion misfire codes under safe verification conditions.
Clear codes after repair, run the specified monitor or road test, and rescan every relevant module. A short idle without the warning is not enough.
P0313 OEM Differences and DIY Limits
Tank shape, saddle transfer, pickup design, pressure strategy, cylinder numbering, misfire counters, and low-fuel inhibit logic vary by platform. Match the OEM description, diagram, terminals, test conditions, and bulletins to the full VIN.
How many level senders, pickups, pumps, or transfer devices does this tank use?
What did the controller consider low fuel, and was the level signal plausible?
Which pressure, injector, ignition, and mechanical tests are safe and specified?
Direct-injection pressure, ignition voltage, catalyst protection, and road-test procedures can require specialist equipment. Stop before unverified probing, programming, hazardous work, or disassembly requiring special tools.
- Save all modules, freeze frame, and fault order.
- Inspect accessible wiring and connectors only after make the vehicle safe and follow the oem precautions before physical testing.
- Inspect accessible connectors with power off.
- Use the correct diagram and approved probes.
- Do not bypass protection, power a component directly, or work around uncontrolled pressure, heat, fuel, exhaust, or moving parts.
- Do not pierce seals or spread terminals.
- Do not run unsupported commands or programming.
- Escalate for special tools, disassembly, or controlled hazards.
Frequently Asked Questions About P0313
Does P0313 prove the fuel pump is bad?
What does “with low fuel” mean?
Can I keep driving with P0313?
Can a weak battery affect P0313?
Can MA500 diagnose P0313?
Is a continuity or resistance check enough?
Should I clear the code before testing?
How is the repair verified?
Sources and Technical Review Notes
- Ford Safety Recall Service Instructions — Lists P0313 as Misfire Detected With Low Fuel and preserves application context rather than a universal repair.
- Volkswagen Misfire Diagnostic Aid — Emphasizes saving environmental conditions and considering multiple misfire causes; its low-fuel examples are application-specific.
