P0322 Code: Engine Speed Input Circuit No Signal

P0322 Engine Speed Input Circuit No Signal diagnostic illustration
ENGINE SPEED INPUT: NO SIGNAL

P0322: Trace the Missing Speed Input

Confirm that a signal should exist, identify its actual source and determine whether it is generated and reaches the controller.

Updated September 8, 2026About 12 min readBy iCARZONE

DIAGNOSTIC FOCUS

NO SIGNAL
FAULT TYPE
Missing monitored engine-speed information
FIRST CHECKS
Actual source, cranking context, electrical support and signal path

No signal is not simply low RPM, and the generic distributor wording does not identify a distributor on every engine.

QUICK ANSWER

P0322 means Ignition/Distributor Engine Speed Input Circuit No Signal. The controller did not receive the expected engine-speed information under its monitoring conditions. Identify the vehicle-specific source before selecting a pickup, ignition component or crankshaft sensor. The generic wording is not a universal parts name.

Save the full scan and starting or stalling history. Confirm actual engine rotation and valid electrical support, then test whether the source generates the required signal and whether it reaches the receiving controller. A zero-RPM display alone does not establish which component or wire failed.

What Does the P0322 Code Mean?

Ignition/distributor is historical diagnostic wording. Modern engines may obtain speed input without a conventional distributor. Use the exact engine diagram and OEM description to identify the monitored source and signal route before ordering parts.

Interpret no signal in the required operating state. Zero RPM with the engine stopped is expected. During no-start diagnosis, confirm actual engine rotation and whether the conditions for expecting an input are satisfied.

The signal may never be generated, lose electrical support, disappear along the harness or fail at the receiving module. Mechanical rotation or target defects require supporting evidence. A missing scan value does not prove a failed crank sensor.

Correct speed-input source

Identify the actual pickup, reference electronics and receiving controller.

Valid signal-expectation state

Record engine rotation, cranking support and the original event.

Source-to-controller comparison

Determine whether the signal exists at its source and reaches the required input.

Separate no-crank from cranks-but-will-not-start. A starter sound alone does not establish correct engine rotation. Describe the actual behavior and follow the appropriate prerequisite checks before interpreting an absent speed signal.
P0321: Engine Speed Input Range/PerformanceP0322: Engine Speed Input No SignalP0323: Engine Speed Input IntermittentP0335: Crankshaft Position Sensor A Circuit

P0322 Symptoms, Severity, and Driving Safety

Cranks but will not start
Preserve the event without exceeding the starter's permitted duty cycle.
Stalls or cuts out
Stop unsafe operation and arrange diagnosis rather than repeated traffic tests.
No reported RPM during an attempted start
Confirm parameter support, actual rotation and measurement context.
Intermittent starting after cooling
Record temperature and time context without assuming a heat-failed sensor.
Related cam, supply or communication records
Compare their timing and relevance before deciding on a common cause.
Abnormal cranking sound or mechanical noise
Stop further attempts and obtain qualified inspection.

Prompt no-start diagnosis; repeated stalling requires stopping

Stop for repeated stalling, unsafe power loss, abnormal cranking noise, smoke or electrical overheating. Do not exceed the actual starter duty cycle or defeat starting interlocks. Keep test leads away from belts, fans, hot parts and high-voltage ignition components. Arrange recovery when the vehicle cannot operate reliably.

P0322 Causes and the Evidence That Separates Them

These six branches describe reasons to test the actual signal path. They are not ranked causes or proof that any listed component has failed. The engine architecture determines which electrical supports and physical targets exist.

1

Disconnected or poorly retained source connector

The expected input may be interrupted at a connector after service or through contact deterioration.

How to prove it: Inspect the correct connection and retention using approved terminal checks. Do not mistake a nearby cam or knock-sensor connector for the speed source, or enlarge terminals with unsuitable probes.

Confirm connector seating
2

Open, short or unwanted connection in the harness

The source signal may fail to reach its destination or be distorted along the route.

How to prove it: Compare the approved source and receiver test points with the required connection states. Use suitable signal equipment; an inappropriate continuity test alone cannot establish a healthy operating waveform.

Trace signal continuity
3

Missing sensor or reference-electronics support

An active pickup or intermediary module may lack the electrical conditions it needs.

How to prove it: Identify the actual technology before testing supply and returns. Do not assume every pickup is powered, uses the same voltage or can be evaluated with a generic resistance check.

Check required support
4

Failed or incorrect speed pickup or reference electronics

The identified source may not produce the required information despite correct support and rotation.

How to prove it: Check the correct part and capture source output using the specified method. A zero scan RPM reading alone does not prove source failure; verify the physical signal and its necessary conditions.

Prove source output
5

Target, clearance or mechanical-rotation problem

The source may not encounter the expected target or mechanical relationship.

How to prove it: Use the actual inspection and waveform evidence before this conclusion. Do not prescribe a universal air gap, assume a jumped timing belt or continue cranking through abnormal mechanical sounds.

Inspect rotation and target
6

Controller input or replacement-configuration issue

A receiving module or incorrect setup remains possible after external paths are tested.

How to prove it: Prove the required signal reaches the correct input with valid module support. Confirm parts and current service applicability before configuration or controller work; no-signal wording alone does not justify replacement.

Validate receiver branch

A missing input at the controller and a missing output at the source are different observations. Keep measurement locations and test conditions in the record so wiring, support and source defects are not combined into an unexplained parts list.

Using MA200 Plus During P0322 Diagnosis

The iCARZONE MA200 Plus can help retrieve supported engine faults and inspect available cranking RPM or related status on a covered vehicle. Preserve full descriptions and companion records before disconnecting components or clearing the original no-start event.

Confirm the required RPM and synchronization parameters. General engine diagnostics do not guarantee every OEM speed input, cam/crank status or module record. Check vehicle and ECU support, parameter identity and update behavior before using one display as diagnostic evidence.

A scan tool reports processed controller data, not an independent pickup waveform. Zero or stale RPM may reflect several conditions and must be interpreted with actual rotation and electrical testing. Use appropriate signal equipment at the specified points when the procedure requires source-to-controller comparison.

RECOMMENDED DIAGNOSTIC TOOL

iCARZONE MA200 Plus Multi-System OBD2 Diagnostic Scanner

iCARZONE MA200 Plus diagnostic scanner for preserving P0322 fault evidence
Supported engine scan · cranking RPM · companion records

Preserve the no-start or stall record and identify the actual speed-input source before tracing its physical signal path.

$144.99
$179.99
Check MA200 Plus Coverage

No reset or active test is offered as a universal no-signal repair. Do not bypass interlocks, command unsafe cranking or use starting fluid to work around missing information. After repairing the demonstrated branch, perform only the setup and verification required for that exact engine and component.

How to Diagnose P0322 in 6 Steps

Use these six stages with current engine-specific diagrams and pinpoint instructions. They define the source technology, expected rotation, support conditions, suitable instruments and safe cranking limits. No universal waveform, resistance range or pickup air gap is prescribed.

P0322 Quick Diagnostic Path

  • 1

    Save the full scan and starting history

    • Record the complete descriptions, reporting modules, status and available event data before resetting or disconnecting anything.
    • Distinguish no-crank, cranks-but-will-not-start and running stalls. Retain recent wiring or engine work and stop repeated attempts if unsafe conditions develop.
  • 2

    Identify the actual monitored source

    • Use engine and controller information to map the pickup or reference electronics and their connection to the receiving module.
    • Do not infer a conventional distributor, crank sensor location or connector from generic terminology. Confirm the actual circuit role and source technology.
  • 3

    Verify rotation and the required support

    • Follow the appropriate checks for actual engine rotation, cranking conditions and the electrical supports needed by the source and controller.
    • An engine-off zero reading is not proof of a fault. Respect starter duty-cycle limits and do not bypass interlocks or ignore abnormal mechanical noise.
  • 4

    Measure source output with appropriate equipment

    • Capture the expected signal at the prescribed source points using the actual connection state and service method.
    • Match the instrument to the sensor technology. A universal resistance test or missing scan PID cannot substitute for the required waveform or electrical observation.
  • 5

    Compare the receiving input and isolate the loss

    • Determine whether the valid source information reaches the specified controller input and compare relevant reference signals when required.
    • Trace wiring and support defects before module conclusions. If source output is absent, use evidence to distinguish electrical support, source condition and target or rotation problems.
  • 6

    Repair the evidenced branch and verify

    • Correct the demonstrated connection, source, support or physical defect and restore specified retention, routing and protection.
    • Complete required setup and verify reliable starting or running and the relevant monitor. Retain final data; one successful start or a cleared code is insufficient.
Avoid moving parts, hot components and high-voltage ignition circuits. Use the actual starter rest periods and secure the vehicle before tests. Never defeat a starting interlock, inject power into unknown signal wiring or continue through abnormal mechanical noise to obtain a waveform.

How to Fix P0322 and Verify the Repair

01

Restore the proven signal connection

Repair the actual connector or conductor defect and its underlying routing or retention cause.

02

Correct a demonstrated support problem

Restore the identified supply or return appropriate to the actual source technology.

03

Replace a verified failed or incorrect source

Use the correct pickup or reference component with required setup.

04

Repair evidenced target or receiver conditions

Follow the physical or module test results rather than assuming a universal crank sensor or distributor repair.

01

No-signal diagnosis

VIN-specific quote
Main cost driver

Ask whether actual rotation and source-to-controller comparison are included.

02

Electrical-path repair

VIN-specific quote
Main cost driver

Request the measured location where support or signal is lost.

03

Source or mechanical work

VIN-specific quote
Main cost driver

Require the evidence, correct component identity and required access before authorizing replacement.

04

Final verification

VIN-specific quote
Main cost driver

Include required setup, reliable operation and final signal or monitor records.

Request an itemized estimate after identifying the failed branch. A connector repair, pickup replacement and mechanical target issue require different work. P0322 does not establish a universal price or justify replacing the entire ignition system.

If the event returns, compare the original source, measurement points and conditions. Review intermittent contacts, unresolved support or incorrect parts before further replacement. Preserve evidence instead of repeatedly clearing the warning.

P0322 OEM Differences and DIY Limits

Volkswagen's February 2014 Passat reference book gives engine-code-specific P0322 examples in which engine-speed information is absent while camshaft activity is present. This illustrates a monitored relationship that indicates speed information should be available; it does not identify a conventional distributor or automatically prove the speed pickup failed.

Signal expected from context

The VW examples compare missing speed information with cam activity.

Engine-specific monitoring

Different engine sections retain their own criteria.

No automatic component verdict

The source, wiring and receiving input still require diagnosis.

The same book contains different engine sections and counting criteria. Those values are not transferred here. Obtain current VIN-specific information for the actual source, receiving input, waveform and safe operating conditions. A historical monitor table cannot replace the physical circuit test or establish a universal cranking duration.

Reasonable DIY Checks
  • Save exact codes and starting behavior.
  • Record whether the engine actually cranks.
  • Note recent electrical or engine work.
  • Ask where the signal is proven absent.
Professional-Level Work
  • Do not order a distributor from the generic wording.
  • Do not bypass starting interlocks.
  • Do not use a universal pickup-resistance value.
  • Do not continue driving a vehicle that repeatedly stalls.

Related Speed, Camshaft and Signal-Circuit Guides

Compare the actual source and monitor category before using another guide. Engine-speed, camshaft, vehicle-speed and internal RPM records may share symptoms without referring to one sensor or an interchangeable diagnostic procedure.

For other stored faults, use the iCARZONE OBD-II fault-code center.

Frequently Asked Questions About P0322

What does P0322 mean?
It means ignition/distributor engine-speed input circuit no signal. Identify the actual source and operating conditions from current vehicle-specific information.
Does my engine definitely have a distributor?
No. The generic wording is historical. A modern system can obtain the relevant information through a different pickup or electronic reference arrangement.
Does zero RPM on the scanner prove a bad sensor?
No. Confirm actual rotation, parameter meaning, data update and electrical conditions. Then establish whether the required signal exists at the source and receiver.
Is this simply low engine speed?
No. No signal describes absent monitored information under the applicable conditions. Low physical speed and a missing input need to be distinguished by the actual test.
Should I replace the crankshaft sensor first?
Not without identifying the source and proving the fault. The signal may be lost through wiring, support, target conditions or receiving electronics rather than the assumed component.
Can MA200 Plus show the physical waveform?
A scan display shows supported processed data, not an oscilloscope trace. The actual procedure may require separate signal equipment and reference measurements.
Can I keep cranking until it starts?
Follow the actual starter duty cycle and stop for abnormal noise, heat or smoke. Do not bypass interlocks or repeat unsafe attempts to obtain a reading.
What verifies the repair?
Confirm the evidenced defect is corrected, required setup is complete and safe operation and monitor results are satisfactory. One successful start or a reset alone does not prove it.

Sources and Technical Review Notes
