STOP — READ BEFORE YOU BUY PARTS

P0642 Code: Don't Replace Your ECU Yet

P0642 means the 5V reference voltage feeding your engine sensors has collapsed below 4.5V — most commonly because a wire chafed through to ground, NOT because the ECU is dead. Classic Audi S3 8L (2000-2003), VW Mk4 GTI/R32, GM Silverado/Tahoe, Ford F-150, and Chrysler Hemi platforms are notorious for this. The €800-€1,500 ECU replacement your dealer quoted is the right fix less than 10% of the time. About 60% of cases are a €20 wiring repair you can do yourself.

Updated May 2026 11 min read DIY Difficulty: Moderate Fix Cost: €0 – €1,500

What Does P0642 Actually Mean?

P0642 is defined as Sensor Reference Voltage A Circuit Low. The ECU outputs a steady 5.0V supply (the "5V reference A") to power a group of sensors that share that line. When the ECU's own monitoring sees that voltage drop below approximately 4.5V for 10+ consecutive seconds, it sets P0642.

The 5V reference is not just for one sensor — it's a shared bus. On most platforms, the same 5V line feeds the MAP, TPS, APP (accelerator pedal position), and sometimes the coolant temp and crank position sensors. If any one of those sensors shorts to ground internally, OR if any wire on that bus chafes through to chassis metal, the whole bus drops. The ECU sees the sag and sets P0642 — plus often a bunch of secondary sensor codes from the other sensors on the same bus, which all suddenly send bogus data.

That shared-bus behavior is the key to diagnosing P0642 efficiently. If P0642 comes alone, the issue is upstream (ECU output or wiring near the ECU). If P0642 comes with three or four sensor codes (P0102, P0121, P2138, etc.) all at once, the issue is downstream — one of those sensors or their wiring is dragging the whole bus down.

The number that matters: on virtually every OBD-II vehicle, 5V reference A reads 5.0V ±0.2V (i.e. 4.8-5.2V) at any sensor's reference pin, key-on engine-off. P0642 sets below ~4.5V for 10+ seconds. Reference voltage B (a separate 5V line) gets its own code: P0652.
The P064x code family: P0641 (5V ref A circuit open), P0642 (5V ref A low — this one), P0643 (5V ref A high), P0651 / P0652 / P0653 (5V ref B variants). P0642 and P0652 often appear together when a wire is chafed in a spot where both reference busses run — if you see both codes, focus on the harness section common to both, not on swapping sensors one at a time.

Symptoms of P0642

Power loss — sometimes severe; Audi S3 8L 1.8T typically drops from 210 hp to 150-170 hp
Rough idle — RPM swings 800-1,200, worst at cold start
Limp mode / no throttle response — PCM substitutes default values when sensor data is unreliable
Hard start — especially cold; sometimes won't start at all if voltage is well below 4V
MPG drop — 15-20% increase in fuel consumption (8.5 L/100km → 10-11 L/100km on S3 8L)
Multiple sensor codes — P0102 (MAF/MAP), P0121 (TPS), P2138 (APP) appearing together = shared-bus failure

If P0642 came on after recent engine bay work (intake manifold service, turbo job, alternator replacement), a pinched wire is the dominant suspect. If it appeared spontaneously on a high-mileage or aging vehicle, harness wear from heat and vibration is more likely.

What Causes P0642? (Ranked Cheapest First)

Wiring problems dominate this code's cause distribution — work the order; the first three resolve 80% of P0642 cases without touching the ECU.

1

Wiring harness chafed through to ground

The dominant cause across all platforms — 60% of P0642 on the Audi S3 8L, 50-70% on most others. Heat from the turbo or exhaust manifold, plus 20+ years of engine vibration, cracks the harness insulation. Eventually a wire on the 5V bus rubs through to a grounded surface (chassis bracket, manifold heat shield, valve cover) and shorts the 5V reference down to 0-2V. On classic Audi/VW 8L/Mk4 platforms, the failure spot is almost always behind the engine where the harness routes between the turbo and the firewall.

How to find it: Visual inspection along the harness route, paying attention to: where the loom passes the turbo / exhaust manifold heat shield, where it touches valve cover bolts or intake brackets, sharp bends near the cabin firewall. Use a flashlight and a mirror to get behind the engine. Look for melted plastic, exposed copper, black scorch marks. Repair with weatherproof heat-shrink butt connectors and reroute or sleeve the loom away from heat.

Fix: €20-€60 · DIY 1-2 hr
2

Corroded sensor connector on the 5V bus

About 20% of cases on the S3 8L and similar-era European cars, less on newer platforms. Water intrusion from a leaky cabin air filter housing or aging engine bay seal lets corrosion build up on a sensor connector. Higher contact resistance partially shorts the 5V reference. Often the affected sensor's own code (e.g. P0107 for MAP, P0122 for TPS) sets right next to P0642.

How to find it: Disconnect each sensor on the 5V bus one at a time (MAP, TPS, APP, sometimes coolant). Inspect each connector under light: green/white corrosion powder, blackened pins, melted plastic, water residue. Clean with electrical contact cleaner + brass brush. Replace damaged pins from a connector repair kit. Dielectric grease, reseat firmly.

Fix: €15-€40 · DIY 30 min
3

Shorted sensor on the 5V bus (MAP, TPS, APP, etc.)

About 10-15% of cases. A sensor on the shared 5V bus develops an internal short. When the sensor's internal resistance falls toward zero, it pulls the entire 5V line down. Symptoms tend to come on suddenly (often after a hard rain or a winter cold snap). On the S3 8L the OEM MAP sensor (#038906051) and TPS (#06A907385) are both common offenders past 20 years; on GM trucks the APP sensor; on Chrysler Hemi the MAP sensor.

How to find it: The disconnect test. With a scan tool reading live 5V reference A, unplug one sensor at a time. The instant voltage jumps back to ~5.0V, you found the shorted sensor. Don't skip this step — it tells you the answer in 5 minutes and saves you from blindly swapping parts.

Fix: €60-€150 · DIY 30 min
4

Weak battery or alternator pulling system voltage down

About 5% of cases, often missed. The ECU needs a solid 13.5-14.5V input to generate a stable 5V reference. If the battery is below 12V or the alternator is putting out less than 13V at idle, the ECU can't regulate cleanly and the 5V reference drifts low. Common on classic cars with aging alternators or batteries past 5 years.

How to find it: Multimeter at the battery: engine off should read 12.4-12.7V; engine running at idle should read 13.5-14.5V. Anything below those = charging system problem. Address the battery/alternator first; P0642 often clears on its own once supply voltage stabilises.

Fix: €0-€150 test · €180-€450 alternator
5

Poor ECU ground or corroded ECU connector

About 3-5% of cases. The ECU shares a ground point with the engine block or chassis. If that ground bolt corrodes or loosens, ECU internal voltage references drift — including the 5V output. On the S3 8L the main ECU ground is on the firewall under the cabin air filter housing; the same housing that lets in water and corrodes the connector. Two birds, one stone.

How to find it: Locate the ECU ground bolt (factory wiring diagram or marked with a star symbol on most VAG cars). Loosen, inspect both sides of the connection for corrosion, clean to bare metal, apply anti-seize, retorque. Inspect the main ECU connector for the same. Often a 20-minute cleanup resolves everything.

Fix: €0-€10 · DIY 30 min
6

Damaged ECU connector pins or sockets

About 3% of cases. The 5V reference pin in the ECU connector itself gets bent, pushed back, or corroded — same effect as a chafed wire but at the source. Common after botched repair work where someone disconnected and reconnected the ECU connector without realigning the pins.

How to find it: Unplug the ECU. Inspect the connector face for: bent or pushed-back pins, blackened terminals, melted plastic, oil contamination. Re-pin with a universal terminal kit. Apply dielectric grease before reseating.

Fix: €5-€20 · DIY 45 min
7

Aftermarket sensor with the wrong electrical spec

About 2% of cases, but always self-inflicted. Someone installed a cheap aftermarket MAP, TPS, or APP that draws too much current on the 5V bus. The bus sags whenever that sensor is energised. Returns to spec the moment the OEM sensor goes back in.

How to find it: Service history check. Any sensor replaced in the last 6 months with a non-OEM part? Pull it, refit the OEM, retest. If P0642 disappears, you've confirmed the cause. Always use OEM sensors on these older platforms.

Fix: €0 if you have the OEM · €60-€150 to buy one
8

Failed internal ECU 5V regulator (last resort)

Less than 10% of cases — the dealer's default but statistically the least likely cause. The ECU has an internal 5V regulator chip. After 20+ years it can fail, especially on cars that have suffered voltage spikes from a bad alternator diode or a botched jump start. Diagnosis is by elimination only.

How to find it: All other causes ruled out: wiring intact (no shorts to ground), no sensor pulls voltage down on the disconnect test, ground bolt clean, ECU connector pins healthy, charging system in spec — yet P0642 returns. Only then suspect the ECU. Send to a reman specialist (Module Master, DTUK, etc.) rather than buying a dealer-priced new unit. Coding is mandatory after install.

Fix: €400-€900 reman · €800-€1,500 dealer

What You'll Need

Tools

  • Scan tool with live reference voltage data + classic protocols (KWP2000) iCarzone UR 800 ›
  • Digital multimeter (4-digit, mV precision) €25-€50
  • Back-probe pin set or T-pins €10-€20
  • Electrical contact cleaner + brass brush €8-€15
  • Heat-shrink butt connectors (weatherproof) €10-€20
  • Inspection mirror + LED flashlight €10-€20

Possible Parts

  • Universal terminal repair kit €10-€20
  • Dielectric grease €5-€10
  • Heat-resistant loom tape / split-loom sleeving €10-€25
  • Audi S3 8L MAP sensor (#038906051) €80-€120
  • Audi S3 8L TPS (#06A907385) €60-€90
  • Alternator (only if charging system test fails) €180-€450
Recommended Diagnostic Tool for P0642

iCarzone UR 800 Bidirectional Scan Tool

★★★★★ 5.0 · Bidirectional + ECU coding

Supports KWP2000, K-line, and CAN protocols — works on classic Audi S3 8L (2000-2003), VW Mk4, BMW E46, and every modern OEM. Reads live 5V reference voltage, runs the disconnect test workflow, and does ECU coding after reman.

$299.99
Was $699.99
Shop Now ›
Need to read live 5V reference voltage on a 2000-2003 Audi or VW? Most cheap scanners can't even connect to KWP2000 cars. The UR 800 reads live reference voltage A and B on the S3 8L, Mk4 GTI/R32, A4 B6, plus every modern OEM — the only diagnostic that tells you whether the wiring or the ECU is at fault.
Shop the UR 800 →

How to Diagnose P0642 at Home

Total time: 45-90 minutes. The disconnect test in step 4 is the highest-value 5 minutes you can spend on this code — it tells you the answer faster than any other technique.

  • 1

    Read all codes and freeze-frame data

    Pull every code. The pattern is everything on a 5V reference fault:

    • P0642 alone → likely an upstream issue (ECU output, ECU ground, wiring near the ECU).
    • P0642 + several sensor codes (P0102, P0107, P0121, P2138) → the whole 5V bus is sagging; one downstream sensor is shorting it.
    • P0642 + P0652 → both reference busses are affected; look for a single chafed harness section that passes both.
    • P0642 + battery / charging codes → charging system first.

    Freeze frame: capture battery voltage, RPM, coolant temp at the moment P0642 set. Sets at cold start = wiring or connector. Sets at warm idle = sensor short. Sets at WOT only = chafe that only contacts ground when the engine moves on its mounts.

  • 2

    Check supply voltage first

    Always start here. If the ECU isn't getting enough input voltage, no diagnosis downstream will be reliable.

    1. Multimeter at the battery, engine off: should read 12.4-12.7V.
    2. Start engine, multimeter at battery again: should read 13.5-14.5V at idle.
    3. Below specs = charging system issue; replace battery and/or alternator before continuing.
    4. Above 15V = overcharging alternator; replace before continuing (overcharge damages ECU).
  • 3

    Read live 5V reference voltage with a scan tool

    Use a scan tool that exposes reference voltage A as live data. UR 800 reads this on KWP2000 (Audi S3 8L, VW Mk4) and modern CAN platforms.

    1. Key on, engine off. Read live data: "Reference Voltage A" or "5V Ref A".
    2. Spec: 4.8-5.2V. Anything below 4.5V at key-on confirms P0642 is active.
    3. Start engine. Watch the value at idle, snap throttle to 2,500 RPM, hold.
    4. If voltage dips with engine vibration = mechanical wiring issue (chafe that only contacts under engine movement).
    5. If voltage steady-low across all states = constant short to ground or weak ECU output.
    Tip: If your scan tool can graph reference voltage over time, leave it logging while you wiggle the harness sections with the engine running. A clear correlation between hand pressure on a section and a voltage dip pinpoints the exact failure spot — no guessing required.
  • 4

    The disconnect test (5 minutes, free, definitive)

    The single most useful technique for P0642. With reference voltage A on the scan tool's live data screen:

    1. Identify the sensors that share reference voltage A. On the Audi S3 8L: MAP, TPS, coolant temp. On most modern platforms add APP.
    2. Engine off but key on (so the ECU is powered). Reference voltage reads <4.5V (P0642 active).
    3. Unplug one sensor on the bus. Read the voltage value:
    4. Voltage jumps to 5.0V ±0.2V → that sensor is the shorted part. Replace with OEM and retest.
    5. Voltage stays low → reconnect the sensor, try the next one.
    6. Voltage stays low even with every shared sensor unplugged → issue is upstream: wiring chafe or ECU output.
  • 5

    Visual harness inspection (if disconnect test cleared all sensors)

    Now the patient work. Engine off and cool.

    • S3 8L / Mk4 GTI / A3 8L: harness section behind the engine between the turbo and the firewall. Common chafe point against the heat shield.
    • GM trucks / SUVs: harness running along the upper intake manifold to the throttle body / TPS / MAP.
    • Ford F-150 5.0: harness section near the alternator and PCV plate.
    • Chrysler Hemi: harness routing under the upper intake plenum, especially around cylinders 5-8.

    Look for: melted insulation, exposed copper, black scorch marks, bite marks (rodents), green/white corrosion. Repair with weatherproof heat-shrink butt connectors. Re-route the loom away from heat with sleeving or loom tape.

    Warning: Disconnect the battery negative for 5 minutes before any wiring repair. The ECU stays powered for 10-30 seconds after key-off on some platforms — cutting a hot 5V wire can blow the internal 5V regulator and turn a €20 repair into a €800+ ECU replacement.
  • 6

    Clean ECU ground and check the connector

    Often skipped, often the answer on older European cars.

    1. Locate the main ECU ground (factory wiring diagram). On the S3 8L it's on the firewall behind the cabin air filter housing.
    2. Remove the bolt. Inspect both surfaces (ring terminal and chassis) for corrosion, green powder, paint contamination.
    3. Clean both surfaces to bare metal with a wire brush. Apply anti-seize compound. Retorque to spec.
    4. While you're there, unplug the ECU connector. Inspect pins: bent, pushed-back, blackened, corroded. Re-pin if needed. Dielectric grease, reseat firmly.
  • 7

    Test for shorts to ground with a multimeter

    If steps 4-6 cleared everything but P0642 still returns, do a continuity test.

    1. Battery disconnected, key off, all sensors disconnected, ECU unplugged.
    2. Multimeter on Ω (ohms) scale.
    3. Test continuity between the 5V reference A pin at the ECU connector and a known good chassis ground point.
    4. Spec: open circuit (infinite or O.L.). Any reading below 100Ω = wire is shorting to ground somewhere on the harness. Repeat step 5 with more focused attention until you find it.
    5. Spec OK = wiring is intact. P0642 is either ECU internal or ECU ground (last verify step 6, then suspect ECU).
  • 8

    Verify the fix with a full drive cycle

    After any repair:

    • Reconnect everything to torque spec.
    • Clear all codes; reset ECU adaptations via scan tool (recommended on older Audis after sensor work).
    • Cold start: verify smooth idle, no warning lights, scan tool shows reference voltage A at 4.8-5.2V steady.
    • Drive 50+ km mixed conditions including at least one cold start and a couple of WOT pulls.
    • Re-scan. P0642 gone, reference voltage stable at 5.0V ±0.2V across all conditions, for 2-3 drive cycles = permanently fixed.

How Much Does P0642 Cost to Fix?

Repair DIY Cost Shop Cost You Save Type
ECU ground cleanup (cause #5) €0-€10 €100-€200 Up to €200 Try First
Sensor connector clean + dielectric grease €15-€30 €120-€220 Up to €205 Try First
Wiring harness repair (chafe through) €20-€60 €250-€500 Up to €480 DIY Moderate
ECU connector pin re-pin €5-€20 €150-€280 Up to €275 DIY Moderate
MAP sensor OEM (#038906051 on S3 8L) €80-€120 €250-€350 Up to €270 DIY Friendly
TPS OEM (#06A907385 on S3 8L) €60-€90 €200-€280 Up to €220 DIY Friendly
APP sensor OEM €70-€160 €220-€380 Up to €310 DIY Friendly
Battery replacement (5-year spec) €80-€180 €150-€280 Up to €100 DIY Friendly
Alternator replacement (OEM, S3 8L) €180-€450 €500-€900 Up to €450 DIY Moderate
ECU reman + coding (worst case) €400-€900 €1,000-€1,500 Up to €600 Shop Advised

Which Vehicles Get P0642 Most Often?

Make / Model Years Engine Primary Cause & Notes Risk
Audi S3 8L / S3 8P (early) 2000-2008 1.8T / 2.0T Harness chafe behind turbo. Highest P0642 rate per classic VAG forums. High
Audi A3 8L 2000-2003 1.8T / 1.8 Same 8L platform as S3 — same chafe pattern, slightly less heat exposure. High
VW Golf Mk4 GTI / R32 2000-2005 1.8T / 3.2 VR6 Shared platform with S3 8L. R32 V6 packaging makes harness access worse. High
VW Bora / Jetta Mk4 2000-2005 1.8T / 2.0 / 1.9 TDI Same Mk4 chassis, same chafe failure modes. Medium
Chevy Silverado / Tahoe / Suburban 2007-2014 5.3L / 6.2L V8 Harness running along upper intake; APP sensor is the most common shorted device. High
GMC Sierra / Yukon 2007-2014 5.3L / 6.2L V8 Same GM truck platform; same APP / TPS shorting pattern. High
Ford F-150 2004-2014 5.4L Triton / 5.0 Coyote Harness chafe near alternator and PCV plate is the dominant cause. Medium
Chrysler 300 / Charger / Challenger Hemi 2005-2014 5.7L / 6.4L Hemi MAP sensor short under upper intake plenum is documented in multiple TSBs. Medium
BMW E46 / E90 3-Series 2000-2011 M52 / M54 / N52 Less common than Audi but happens. DME ground bolt corrosion is the typical cause. Medium
Honda Civic / Accord 2003-2012 2.0L / 2.4L K-series APP sensor short is the common cause; usually pairs with P2138. Lower
Toyota Tacoma / Hilux 2005-2015 2.7L / 4.0L V6 Rare but documented; usually a chafed wire near the throttle body. Lower
Subaru Forester / Outback 2008-2014 2.5L H4 MAP / APP shared bus shorts after water intrusion into engine bay. Lower
Audi S3 8L (and Mk4 GTI / R32) owners — read this: Your harness chafe point is almost certainly behind the engine where the loom passes the turbo / exhaust manifold heat shield. Get a mirror and a strong flashlight in there before you spend a single euro on parts. 60% of S3 8L P0642 cases resolve at this exact spot with €20 of heat-shrink butt connectors and 30 minutes of work. The other big trap on the 8L is the ECU ground behind the cabin air filter housing — also a free fix and worth checking the same day you're under the hood.

Should You DIY or Call a Mechanic?

DIY If You…
  • ✓ Have a scan tool that reads live 5V reference voltage (and KWP2000 for classic VAG)
  • ✓ Can use a multimeter for resistance and voltage tests
  • ✓ Are comfortable with wiring repair (butt connectors, heat-shrink, dielectric grease)
  • ✓ Have a mirror and flashlight to inspect behind the engine
  • ✓ The vehicle is out of warranty (most P0642 victims are well past it)
Use a Mechanic If…
  • → Multiple sensor codes plus charging system codes — deeper electrical issue
  • → Step 7 continuity test suggests the short is inside the main loom (requires harness teardown)
  • → ECU reman / replacement needed and you don't have access to a coding-capable scan tool
  • → Your scan tool can't connect to KWP2000 / K-line (classic VAG, BMW E46 era)
  • → Comfortable with mechanical work but new to electrical diagnosis

Related Codes You May See With P0642

P0641
5V ref A circuit open
P0643
5V ref A circuit high
P0651
5V ref B circuit open
P0652
5V ref B circuit low — often pairs with P0642
P0102
MAF / MAP low — secondary effect on 5V bus
P0121
TPS performance — secondary effect
P2138
APP correlation — secondary effect on 5V bus
P0562
System voltage low — upstream charging issue

Frequently Asked Questions

What does the P0642 code mean?
P0642 means the ECU's 5V reference voltage A output dropped below specification (typically under 4.5V) for 10+ seconds. This 5V line powers a group of sensors that share it (commonly MAP, TPS, accelerator pedal, and others depending on platform). When the shared reference sags, every sensor on that bus sends bad data — which causes power loss, rough idle, and sometimes multiple sensor-fault codes setting at once.
Can I drive my Audi S3 8L with P0642?
Short distances only — the engine runs rough, may stall at idle, and can fail to start in cold weather. Don't drive more than 100 km / 60 miles with active P0642. Continuing to drive under these conditions can damage the catalytic converter and overstress the alternator.
What's the most common cause of P0642 on a classic Audi S3 8L?
Wiring damage. On the 2000-2003 S3 8L (1.8T), the Reference Voltage A harness routes near the hot turbocharger and exhaust manifold. Heat and engine vibration crack the insulation over 20+ years — the wire grounds against chassis metal and the 5V supply sags. About 60% of S3 8L P0642 cases trace to harness damage; only about 10% are an actual ECU fault.
Will replacing the ECU fix P0642?
Almost never — less than 10% of cases. ECU replacement is the dealer's default expensive fix (€800-€1,500 with coding), but the real fault is on the wiring or shared-sensor side of the 5V bus in 90% of cases. Never replace the ECU without first isolating the wiring side via the disconnect test in step 4 of the diagnosis.
What scanner do I need to diagnose P0642 on an older Audi?
A scan tool that supports the older KWP2000 protocol used on 2000-2003 Audi/VW vehicles — many modern code readers only support CAN (2008+) and can't even connect to a classic S3 8L. The iCarzone UR 800 supports KWP2000, K-line, and modern CAN protocols, and reads live reference voltage data on the Audi S3 8L plus most other manufacturers.
How do I find which sensor is shorting the 5V reference?
The disconnect test. With the scan tool reading live reference voltage, unplug one sensor on the bus at a time (MAP, TPS, APP, etc.). The moment voltage jumps back to 5V ±0.2V, you've found the shorted sensor. This is faster and more accurate than swapping parts — and free.
What are the normal 5V reference specs?
On virtually every OBD-II vehicle, the 5V reference A output reads 5.0V plus or minus 0.2V (i.e. 4.8-5.2V) measured at any sensor's reference pin with key on, engine off. P0642 sets when this drops below approximately 4.5V for 10+ seconds. Reference voltage B (P0652) is a separate 5V bus on most platforms.
Why is the Audi S3 8L especially prone to P0642?
Three reasons: the wiring harness on the 1.8T routes near the turbocharger and exhaust manifold (heat damages insulation), the engine bay weather sealing on early 8L chassis lets in water (corrodes connectors), and the cars are now 20-25 years old (insulation cracking is well underway). The same fault profile applies to the VW Golf Mk4 GTI/R32 and Audi A3 8L which share the platform.
How do I confirm P0642 is permanently fixed?
Clear the code, reset adaptations, then drive 50+ km mixed conditions including a cold start and a few full-throttle pulls. Re-scan and verify reference voltage A holds 4.8-5.2V at idle and under load. No P0642 return for 2-3 drive cycles = permanently fixed.
The bottom line: P0642 is a wiring code in 80% of cases — not an ECU code. Run the supply voltage check first, then the disconnect test (5 minutes, free) before you spend anything. On classic Audi S3 8L / Mk4 GTI, the harness chafe behind the engine resolves the majority of cases for €20. Save the ECU replacement for last, after a continuity test proves the wiring is intact. And if your scanner can't connect to a 2000-2003 VAG car, you need one that supports KWP2000 — like the UR 800 — before you can diagnose anything.
Written & verified by
Verified

Automotive Diagnostic Specialists

Our team of ASE-certified technicians and OBD-II diagnostic engineers reviews every article for technical accuracy. Content is based on hands-on diagnostic experience across domestic, Asian, and European vehicle platforms.

10+ years diagnostic experience ASE Certified Last reviewed: May 2026

This article is for informational purposes only. Always consult your vehicle's factory service manual and follow proper safety procedures. iCARZONE is not responsible for damage resulting from improper diagnosis or repair.
