P2146 Code: Test Injector Group A Supply Circuit Open
P2146: Find the Shared Supply Interruption
Map injector Group A, preserve the no-start or misfire event, and load-test the common supply before individual parts.
DIAGNOSTIC FOCUS
- FAULT TYPE
- an open or failed monitored supply to the OEM-defined injector Group A
- FIRST CHECKS
- Exact component identity, loaded electrical integrity, injector supply status, cylinder contribution, misfire, engine speed, fuel pressure and voltage, and companion-code order
Group A may be assigned by wiring and controller strategy; do not assume it equals one cylinder bank.
P2146 means Fuel Injector Group “A” Supply Voltage Circuit / Open. The controller detected an interruption or unacceptable condition in the voltage supply serving the injectors it classifies as Group A.
A shared fuse, relay, splice, connector, harness, or overloaded injector can affect several cylinders at once, so preserve the pattern before disconnecting loads. Save the complete scan and freeze-frame record before clearing anything, then use the exact VIN service information to identify the monitored circuit and approved test points.
What Does the P2146 Code Mean?
P2146 is the diagnostic label for Fuel Injector Group “A” Supply Voltage Circuit / Open. The supply side may be shared while the controller switches individual injector control paths, and the exact grouping varies by engine. It is a monitor result, not a parts order, and it does not by itself prove every injector in the group, the fuel pump, or the engine controller is defective.
An open feed can come from a fuse opened by an overload, relay contacts, a splice, connector, harness damage, or protection triggered by a shorted load. The useful distinction is between loss of the common supply, an individual injector or control-wire fault that pulled the supply down, and a controller or module-protection response. That distinction determines whether the next test belongs at a connector, a power or ground path, a control signal, a hydraulic or mechanical system, or an operating-condition check.
Cylinder misfire pattern, supply voltage under load, fuse condition, relay command, and first-failure order identify whether the group fault is primary or secondary. A scan tool cannot replace the current wiring diagram, connector view, service precautions, and approved test method. Do not import limits or component locations from another model year.
Capture confirmed, pending and history codes, freeze frame, first-failure order, system voltage, and the conditions present when P2146 set.
Identify which cylinders belong to Group A, the common fuse/relay/splice, injector connector supply pins, individual controls, controller, and any separate injector module.
Load-test the shared supply through each protected section, isolate loads only as directed, and compare cylinder contribution and control evidence.
P2146 Symptoms, Severity, and Driving Safety
Loss of supply to several injectors can prevent normal combustion.
The affected group may misfire together.
Individual injector or misfire faults can accompany the group supply code.
The controller may protect drivers or limit operation.
A shorted harness or load can repeatedly open circuit protection.
A splice, relay, terminal, or rub point may reconnect temporarily.
Treat P2146 as a potentially severe fueling and drivability fault. Group injector loss can cause stall or no-start, while an electrical short can overheat wiring.
P2146 Causes and the Evidence That Separates Them
A sound P2146 diagnosis must fit the stored conditions and companion codes. The shared supply is the organizing clue; map the group and protection before focusing on one cylinder.
Open Fuse or Fusible Protection
A protection device may be open because of an overload, short, or unrelated shared load.
How to prove it: Verify both sides under load and find the cause before replacement.
Check firstRelay or Power-Distribution Fault
Worn contacts, control loss, heat damage, or a poor socket can interrupt the group feed.
How to prove it: Compare relay command with loaded input/output voltage and inspect the distribution path.
Check firstOpen Splice, Connector, or Harness
Corrosion, loose terminals, rub-through, or a broken splice can remove supply from several injectors.
How to prove it: Use the diagram to divide the circuit and voltage-drop each section under load.
Verify directlyShorted Injector or Branch
One abnormal load can open protection or force a module to shut the shared path down.
How to prove it: Isolate loads in the OEM sequence and use the specified current/waveform test.
Verify directlyController or Injector-Module Supply Fault
A module power, ground, driver, or protection strategy can create the group record.
How to prove it: Prove external feed, loads, grounds, and communication before module action.
Verify directlyFuel Pressure or Mechanical Companion
Low pressure or mechanical misfire may coexist but cannot create an open supply by itself.
How to prove it: Resolve the electrical group fault, then diagnose any remaining pressure or compression codes.
Final branchNever install a higher-rated fuse or repeatedly replace protection without locating the current path that caused it to open. Test the failed state when possible, document the result, and replace a part only after measured evidence supports it.
Using MA500 as an Electrical Baseline for P2146
The iCARZONE MA500 12V/24V Battery & Charging System Tester with SOH/SOC checks battery SOH/SOC, internal resistance, ripple, cranking, and 12V/24V charging. Use it only to document supply stability during P2146 diagnosis.
MA500 does not read or clear engine fault codes. It provides no freeze frame, ECU live data, or actuator commands. Use separate scan equipment and VIN-specific service information.
Injector service can involve high fuel pressure, hot surfaces, and specialized driver circuits. Use fused measurement leads and the specified depressurization, current, and connector methods. Its battery results cannot identify the fuel-injector Group A supply-voltage circuit or replace the specified loaded test.
iCARZONE MA500 12V/24V Battery & Charging System Tester with SOH/SOC
Use MA500 only to document the battery, cranking and charging baseline. A separate scan tool and OEM procedure are required to read P2146, capture group supply status, cylinder contribution, misfire, engine speed, pressure, voltage and first-failure order, and prove the fault.
Checked September 4, 2026: the public page showed $32.99 USD, no compare-at price, and available status. Recheck the offer, stock, and compatibility.
How to Diagnose P2146 in 6 Evidence-Based Steps
Use this order to preserve the event and avoid parts guesses. Inspect code order and fuse state before cycling power repeatedly because a protected driver or intermittent feed can reset temporarily. Let each result choose the next OEM test.
P2146 Quick Diagnostic Path
-
1
Save the Complete Event
- Record code status, freeze frame, injector supply status, cylinder contribution, misfire, engine speed, fuel pressure and voltage, voltage, and first-failure order.
- Note companion supply, reference, communication, or performance faults.
-
2
Confirm the Exact Hardware
- Use the VIN to identify fuel-injector Group A supply-voltage circuit, its controller, connectors, shared paths, and enable conditions.
- Do not borrow terminals, limits, or locations from another application.
-
3
Inspect the Accessible Path
- Safely inspect locks, seals, corrosion, routing, heat or fluid exposure, grounds, and prior repairs.
- Preserve the failed state; do not pierce seals or spread terminals.
-
4
Compare Command and Result
- Observe injector supply status, cylinder contribution, misfire, engine speed, fuel pressure and voltage during a safe reproduction of the stored crank, start, or running condition.
- Scan data narrows the branch but does not replace the specified physical test.
-
5
Test the Leading Branch
- Follow the OEM order for loaded power, ground, signal, control, continuity, isolation, and system tests.
- Record each result and prove external wiring before parts.
-
6
Repair and Verify
- Correct only the proven circuit, component, mechanical, or applicable calibration fault.
- Restore all disturbed items, run the specified monitor, and rescan.
How to Fix P2146 and Verify the Repair
Repair Power Distribution
Correct the proven fuse cause, relay, socket, splice, or power-feed fault.
Repair Group Harness or Connector
Restore only the failed conductor, terminal, seal, or allowed splice and protect routing.
Replace a Proven Injector Load
Use the correct injector, seals, coding, and fuel procedure after current evidence identifies it.
Repair a Proven Module or Driver
Service the controller or injector module only after every external feed, load, power, and ground passes.
Evidence Capture and Mapping
VIN-specific quoteDiagnosis begins with a complete scan, exact hardware identification, and the current service procedure.
Connector or Harness Repair
VIN-specific quoteAccess, sealed terminals, corrosion, heat damage, and shared splices determine labor.
Component Replacement
VIN-specific quoteParts cost alone is incomplete; access, seals, fluids, setup, and relearn can matter.
Controller or Complex System Work
VIN-specific quoteProgramming, network, internal mechanical, or high-risk procedures need separate proof and estimating.
Record the proven fault and repair. Confirm stable Group A supply under load, normal cylinder contribution, leak-free injector connections, intact protection, and no returning P2146 or cylinder faults.
Clear codes after repair, run the specified monitor or road test, and rescan every relevant module. A short idle without the warning is not enough.
P2146 OEM Differences and DIY Limits
Group A cylinder membership, supply architecture, injector voltage, driver design, fuse sharing, and serviceability vary by engine. Match the OEM description, diagram, terminals, test conditions, and bulletins to the full VIN.
Which cylinders and other loads share the Group A supply on this VIN?
Did the supply open because of distribution failure, overload, or controller protection?
Which fused load, current, injector-coding, and high-pressure procedures apply?
Diesel, gasoline direct-injection, piezo, and port-injection systems need different pressure and electrical methods. Stop before unverified probing, programming, hazardous work, or disassembly requiring special tools.
- Save all modules, freeze frame, and fault order.
- Inspect accessible wiring and connectors only after make the vehicle safe and follow the oem precautions before physical testing.
- Inspect accessible connectors with power off.
- Use the correct diagram and approved probes.
- Do not bypass protection, power a component directly, or work around uncontrolled pressure, heat, fuel, exhaust, or moving parts.
- Do not pierce seals or spread terminals.
- Do not run unsupported commands or programming.
- Escalate for special tools, disassembly, or controlled hazards.
Frequently Asked Questions About P2146
Does P2146 prove the Group A injector set is bad?
What does “Group A” mean?
Can I keep driving with P2146?
Can a weak battery affect P2146?
Can MA500 diagnose P2146?
Is a continuity or resistance check enough?
Should I clear the code before testing?
How is the repair verified?
Sources and Technical Review Notes
- Volkswagen Touareg DTC Chart — Defines P2146 as Fuel Injector Group A Supply Voltage Circuit/Open.
- Audi TT OBD DTC Chart — Provides an application-specific P2146 injector supply-circuit description and illustrates OEM wording differences.
