P2400 Code: EVAP Leak Detection Pump Circuit Diagnosis

P2400 EVAP Leak Detection Pump Circuit Diagnosis diagnostic illustration
EVAP LEAK PUMP CONTROL CIRCUIT

P2400: Check the Pump Electrical Path

Establish why the leak-monitoring pump circuit failed before replacing an assembly or diagnosing a separate vapor leak.

Updated September 10, 2026About 12 min readBy iCARZONE

DIAGNOSTIC FOCUS

CIRCUIT / OPEN
FAULT TYPE
EVAP leak detection pump control circuit
FIRST CHECKS
Supply, connector, harness and pump load

This is a circuit result. It does not by itself prove a leaking gas cap or a failed charcoal canister.

QUICK ANSWER

P2400 means Evaporative Emission System Leak Detection Pump Control Circuit/Open. The controller has identified a problem in the electrical path used to operate the emissions leak-check pump. It does not automatically establish a vapor leak or condemn the pump assembly.

Preserve the full fault event, identify the VIN-specific pump or diagnostic module, and test its supply, connections, control path and electrical load. A separate leak, purge-flow or pressure-feedback fault changes the investigation and needs its own proof.

What Does the P2400 Code Mean?

An EVAP system retains fuel vapor and manages its transfer to the engine. A leak-detection pump helps the vehicle evaluate that system under defined monitor conditions. It is not the fuel-delivery pump, and P2400 is not a fuel-rail-pressure diagnosis.

The wording circuit/open directs attention to electrical control. An interrupted wire, connector problem, missing feed or internal component defect can prevent the expected circuit response. Read the complete OEM description because monitoring strategy and circuit isolation differ between vehicles.

The pump may be a separate serviceable part or included in a larger leak-detection assembly. DMTL is one manufacturer term for a tank-leakage diagnostic module. The generic code does not identify its mounting position, connector terminals or replacement scope.

Electrical evidence

Record the complete fault and use the correct wiring diagram to determine the monitored path and permitted measurements.

Monitor evidence

Preserve readiness, available command or status data and the original operating conditions before a reset changes them.

Leak evidence

Fuel odor, visible damage or a separate leak code warrants investigation, but none makes a circuit test unnecessary.

Neither pump silence nor sound establishes circuit integrity or vapor-system sealing. Confirm command, conditions and measurements.
P2400: Control Circuit/OpenP2401: Control Circuit LowP2402: Control Circuit HighP2403: Sense Circuit/Open

P2400 Symptoms, Severity, and Driving Safety

Check-engine light
Operation may feel normal. The warning does not establish a fuel-delivery failure.
Incomplete EVAP monitoring
An interrupted leak check can leave readiness incomplete. Clearing a code does not prove the original fault is repaired.
No observed pump operation
Missing command, disabled testing or interrupted power can explain silence. Sound alone does not identify the failed part.
Several EVAP codes
Pump, sense, heater and valve faults can share connections. Record the entire code set before separating branches.
Intermittent warning
Record rain, road splash and recent work. Their timing is a lead, not proof of the cause.
Fuel smell or refueling complaint
Investigate the actual complaint safely. The circuit code alone does not establish a leak or abnormal tank pressure.

Arrange prompt diagnosis even if operation feels normal. Follow the owner's manual and stop for liquid fuel, strong persistent vapor odor, damaged fuel hardware, hot wiring or repeated fuse failure. No safe mileage can be guaranteed from this code.

Fuel vapor is flammable. Stop normal testing if fuel is leaking or odor is strong; avoid ignition sources and use qualified assistance. A cleared warning light does not establish that the fuel system is safe.

P2400 Causes and the Evidence That Separates Them

These are test branches, not frequency rankings. Follow the OEM chart and preserve evidence before disturbing connectors or clearing faults.

1

Interrupted harness or control conductor

Road damage, chafing, a poor splice or a disconnected circuit can interrupt the required electrical path.

How to prove it: Map the exact conductor and isolate it as specified. Inspect routing and test the affected section; an intact outer sleeve does not establish continuity or load capacity.

Check first
2

Loose or contaminated connector

Poor terminal retention, corrosion or damaged seals can create unreliable contact at the pump or an intermediate connection.

How to prove it: Inspect both mating halves and the sealing environment. Use the specified terminal method, rather than forcing probes into contacts or assuming cleaning alone restores their grip.

Check first
3

Missing supply or shared circuit problem

A protected feed, relay, fuse connection or applicable ground path may prevent the assembly from operating correctly.

How to prove it: Check the wiring diagram and related faults. Test under the required load and operating state, and find the cause of repeated protection failure instead of fitting a larger fuse.

Verify directly
4

Internal pump or module defect

An open winding or internal electronics fault may produce the circuit result after the external path is verified.

How to prove it: Apply the exact component test and determine whether the pump is serviced separately. Do not energize an unknown module with battery leads or order a canister solely from the code.

Verify directly
5

Damage or contamination around the assembly

Impact, an incorrectly fitted shield, damaged plumbing or water and liquid-fuel contamination can accompany a failed leak-check assembly.

How to prove it: Document the physical condition and determine how it relates to the electrical fault. Correct a proven intrusion or installation problem so a replacement is not exposed to the same damage.

Verify directly
6

Controller output or application issue

A driver concern or an application-specific service action remains possible after the load, wiring and supply pass.

How to prove it: Use the final OEM decision path and verify bulletin applicability by VIN. An old bulletin does not authorize a universal pump replacement, software update or free repair.

Final branch

A pump, heater, pressure sensor and switching valve can share an assembly while retaining distinct circuits and fault definitions.

Using JU2000 During P2400 Diagnosis

The iCARZONE JU2000 can help retain supported DTCs, freeze frame, ECU information and available EVAP data before the original event is altered.

Verify the exact EVAP function. Module access, readiness information, pump or valve commands and feedback vary by VIN and software. General bidirectional capability does not promise the service test named in an OEM document.

Use the scan tool with the current wiring diagram and appropriate electrical equipment. It is not a smoke generator, pressure regulator, multimeter or direct measurement of terminal contact and harness continuity.

RECOMMENDED DIAGNOSTIC TOOL

iCARZONE JU2000 All-System Bidirectional Scan Tool

iCARZONE JU2000 diagnostic scanner for preserving P2400 fault evidence
Supported EVAP data · freeze frame · diagnostic reports

Save the pump-circuit event and available monitor information before disconnecting components or clearing codes.

$589.99
$799.99
Check JU2000 Details

Checked September 10, 2026: JU2000 was $589.99 USD with a $799.99 compare-at price. Recheck current price, availability and the required vehicle functions before purchase.

How to Diagnose P2400 in 6 Steps

Use these six stages with the vehicle-specific procedure. Keep electrical diagnosis separate from vapor-leak testing; no universal pins or test limits apply.

P2400 Quick Diagnostic Path

  • 1

    Preserve the complete EVAP event

    • Record P2400 status, full OEM text, freeze frame and all companion codes. Keep available readiness and pump, pressure or valve information, plus the timing of the warning and recent repairs.
    • Do not start by disconnecting the battery. Preserve a report that allows the original condition to be compared with post-repair results.
  • 2

    Identify the pump and operating strategy

    • Use VIN-specific service information to locate the actual assembly, its connector, shared feeds and controller. Establish whether the relevant test runs with ignition on, after shutdown or through an approved service routine.
    • Key-off does not universally mean the module is inactive. Follow the vehicle's shutdown and disable instructions before reaching wiring or removing components.
  • 3

    Inspect safely before commanding anything

    • Check for fuel leakage, damaged underbody hardware and unsafe wiring. Where safely accessible, inspect seals, connector locks, chafe and components disturbed during earlier work.
    • Stop for strong odor or liquid fuel. Use correct vehicle supports and vapor precautions; do not create sparks or improvise a jumper near the fuel system.
  • 4

    Prove the supply and control path

    • A qualified technician should test the mapped feed, relevant ground and control conductor under the OEM conditions. Compare available command information with direct electrical measurements.
    • Use appropriate load and terminal tools. An unloaded voltage reading or scan command alone does not establish that the connected pump receives a usable electrical supply.
  • 5

    Test the assembly and separate other faults

    • If the external circuit passes, use the specified component or guided test to assess the pump or integrated module. Diagnose documented contamination and accompanying valve, pressure or leak faults through their own branches.
    • An approved smoke test can help a proven leak investigation, but does not repair an open electrical circuit. Never apply unregulated compressed air or a pressure limit from another vehicle.
  • 6

    Repair and verify without premature clearing

    • Repair only the proven conductor, terminal, supply or component defect. Reconnect plumbing and protective parts correctly, complete any required setup, then perform the applicable confirmation sequence.
    • After evidence is saved and the repair is complete, clear eligible codes as directed. Check for a pending return and confirm the EVAP monitor has actually run under its required conditions.
Fuel tanks and vapor lines may require specific pressure-release procedures, especially on electrified vehicles. Do not loosen lines, bypass a valve or improvise electrical tests. Keep flames and sparks away, ventilate properly and use qualified service when access or testing exceeds your equipment.

How to Fix P2400 and Verify the Repair

01

Restore the proven connection or harness

Repair the identified open, high-resistance contact or routing damage with specified terminals, seals and protection. Retest the affected path after assembly.

02

Correct the supply or protection fault

Restore the confirmed feed, ground or relay path. Investigate why a fuse failed and verify the repaired circuit under the proper operating load.

03

Replace only the confirmed faulty assembly

Match the exact pump or module and serviceability to the vehicle. Address documented contamination or physical damage rather than installing a new part into the unchanged fault environment.

04

Confirm both electrical and monitor results

Verify the circuit repair and the emissions self-test separately. A running pump, extinguished MIL or completed drive does not alone prove that the relevant monitor passed.

01

Scan and circuit diagnosis

VIN-specific quote
Main cost driver

Access, diagrams, command availability and intermittent reproduction determine the diagnostic work.

02

Connector or harness repair

VIN-specific quote
Main cost driver

Terminal condition, routing, underbody access and sealing requirements affect parts and labor.

03

Pump or integrated assembly

VIN-specific quote
Main cost driver

Price depends on separate serviceability, contamination, mounting location and required associated components.

04

Confirmation testing

VIN-specific quote
Main cost driver

Include circuit checks, any justified leak test and the time needed to confirm the correct monitor.

Request an estimate naming the failed test and repair scope. Verify current warranty eligibility separately.

Retain both reports and document incomplete monitoring; a reset is not a verified repair.

P2400 DMTL Designs and Safe DIY Limits

These examples illustrate circuit and procedure differences. Current VIN-specific service information controls the repair.

Ford definition reference

Ford's published OBD-II list separates P2400 control circuit/open from control-low, control-high and sense-circuit codes. The list supplies terminology, not a pump location or universal test procedure.

Land Rover DMTL example

SSM69118 discusses specified L405 and L494 vehicles and listed DTCs. It considers an internal pump fault after vehicle checks and explicitly distinguishes cases with only an evaporative leak code.

Maserati diagnostic example

MAS002203 covers DMTL-equipped M157, M156 and M161 gasoline vehicles from model year 2017. It requires preserved reports and checks for external, connection and contamination issues before its scoped replacement decision.

Do not transfer fuse designations, connector pins, pressure targets, pump-current values or software-tool menus between manufacturers. The same standardized label can be implemented in different assemblies.

Reasonable DIY Checks
  • Save codes and available readiness information.
  • Record refueling, warning and repair history.
  • Inspect safely accessible external damage.
  • Verify component identity from the VIN documentation.
Professional-Level Work
  • Avoid improvised jumpers near fuel vapor.
  • Leave tank and sealed-line work to qualified service.
  • Use only approved pressure and smoke procedures.
  • Do not bypass fuses, valves or emissions monitoring.

7 Related EVAP and Electrical Guides

P2401 covers the pump-control low branch; P2418 and P2420 concern switching-valve circuits, while P043F concerns the reference-orifice test. P0560, P2510 and P068A are relevant only when the saved scan or diagram also identifies a supply or relay issue. None makes P2400 a vapor-leak verdict.

For other stored faults, use the iCARZONE OBD-II fault-code center.

Frequently Asked Questions About P2400

What does the P2400 code mean?
It means Evaporative Emission System Leak Detection Pump Control Circuit/Open. Identify the actual pump and complete OEM fault text before choosing electrical tests.
Is P2400 a fuel pump code?
It refers to the EVAP leak-check pump, not automatically the pump delivering fuel to the engine. A fuel-delivery complaint needs its own diagnosis.
Will replacing the gas cap fix it?
A cap can have a separate sealing defect, but P2400 does not establish that. Prove the pump control circuit rather than using cap replacement as the default repair.
Does a silent pump prove it has failed?
No. The test may not be enabled, a command may be unavailable or the supply may be interrupted. Confirm operating conditions and electrical evidence before condemning it.
Should the EVAP system be smoke-tested first?
An isolated circuit/open fault requires electrical investigation. Approved smoke testing belongs where a separate leak or the exact OEM procedure justifies it, with the specified equipment and limits.
Can JU2000 perform the OEM leak-test routine?
Only if the exact vehicle and software support the required function. Verify coverage; a general active-test feature does not guarantee every manufacturer's service routine.
Is it safe to drive with P2400?
Follow the warnings and arrange diagnosis. Stop for visible fuel, strong persistent odor, damaged tank hardware or hot wiring. The code alone cannot guarantee safe operation or distance.
How do I know the repair worked?
Confirm the repaired electrical path, follow the required output or monitor test and check for returning current or pending faults. Document incomplete readiness instead of calling a reset a repair.

Sources and Technical Review Notes

  • Ford Published OBD-II Code Reference — Page 38 distinguishes P2400 control circuit/open and adjacent pump-control and sense definitions; not a service procedure.
  • Land Rover SSM69118 — Scoped L405 and L494 DMTL concern; external diagnosis and listed-code limits, with leak-only cases distinguished.
  • Maserati MAS002203 Diagnostic Sheet — DMTL-equipped gasoline application example with preserved scans, external inspection and controlled OEM diagnostic steps.
Bottom line: Prove the EVAP pump electrical path before replacing parts. Keep control, sense and vapor-leak findings separate, repair the established cause and verify the actual monitor rather than only clearing the light.
iCARZONE
iCARZONE

Technical sources checked September 10, 2026. This is a source-based diagnostic guide, not a report of a hands-on vehicle repair. Confirm pump integration, circuit design, shutdown requirements, vapor precautions and monitor conditions for the exact VIN.

Educational guidance only. Fuel vapor is flammable and some EVAP hardware operates after shutdown. Use current OEM procedures, approved electrical and leak-test equipment, and qualified service where necessary.
