COOLANT PUMP A CIRCUIT LOW

P2602: Test the Pump-Control Circuit First

Identify the correct coolant loop, preserve thermal data, and prove the low electrical path before replacing a pump.

Updated September 3, 2026About 11 min readBy iCARZONE

DIAGNOSTIC FOCUS

CONTROL CIRCUIT LOW
FAULT TYPE
Coolant pump A electrical control circuit low
FIRST CHECKS
Loop identity, thermal context, power/ground, driver and pump electronics

“Low” describes the monitored control circuit, not coolant level, flow rate, or temperature.

QUICK ANSWER

P2602 means Coolant Pump “A” Control Circuit Low. The reporting controller detected voltage, current, or feedback below the expected electrical range in the path it calls coolant pump A.

Conventional, auxiliary, turbo, hybrid-battery, inverter, charge-air and cabin-heater loops can use different pumps and safety boundaries. Save the complete scan and freeze-frame record before clearing anything, then use the exact VIN service information to identify the monitored circuit and approved test points.

What Does the P2602 Code Mean?

P2602 is the diagnostic label for Coolant Pump “A” Control Circuit Low. Ford and Volkswagen diagnostic materials use P2602 for coolant pump A control circuit low, while the controlled pump and thresholds differ by application. It is a monitor result, not a parts order, and it does not by itself prove that coolant flow is low, that pump A is mechanically seized, or that the engine is overheating.

The output may be relay-switched, pulse-width controlled, low-side driven, high-side driven, or managed by smart pump electronics. The useful distinction is between an electrical circuit-low fault, a pump that is commanded but cannot move coolant, and a separate cooling-system performance or overheating problem. That distinction determines whether the next test belongs at a connector, a power or ground path, a control signal, a hydraulic or mechanical system, or an operating-condition check.

A short to ground, missing feed, high-resistance connection, failed pump electronics, driver protection, or shared supply fault can all create low-circuit evidence. A scan tool can preserve operating context and compare related data, but it cannot replace a current wiring diagram, connector view, service precautions, and any specified breakout leads or measurement method. Do not import pin numbers, thresholds, or component locations from another model year.

Complete Failure Record

Capture confirmed, pending and history codes, freeze frame, first-failure order, system voltage, and the conditions present when P2602 set.

VIN-Specific Circuit Map

Identify which physical pump is A, its coolant loop, controller, fuse or relay, power and ground, command/feedback wiring, connector and any high-voltage service boundary.

Command-to-Result Proof

Compare pump command, current or feedback with circuit voltage, temperature sensors and observed coolant response using the OEM test.

P2602 identifies an electrical low condition; it does not identify the failed part. It cannot by itself prove low coolant, poor flow, a seized pump, thermostat failure, or overheating.
P2600: Pump A OpenP2602: Pump A Circuit LowP2603: Pump A Circuit HighP00B4: Radiator Sensor High

P2602 Symptoms, Severity, and Driving Safety

MIL or Thermal Warning
A controller may store the code and restrict thermal operation.
Protective Fan Operation
Fans or torque limits may be commanded when pump control is unreliable.
Reduced Power
Hybrid, EV or turbo systems may limit output to protect components.
Temperature Imbalance
Loop sensors can diverge if the pump is not operating, but circuit proof still comes first.
Intermittent After Heat or Moisture
A connector, relay or pump electronics may fail with temperature or water entry.
No Immediate Overheat
A circuit code may set before a short drive produces obvious thermal symptoms.

P2602 ranges from a prompt electrical repair to an immediate thermal-safety concern. The code alone does not prove overheating, but loss of a required pump can quickly affect an engine, turbocharger, battery, inverter or cabin-heater loop.

Stop for an overtemperature or high-voltage warning, steam, major coolant loss, reduced-power escalation or abnormal electrical odor. Never open a hot pressurized system. On hybrid or EV platforms, observe the published high-voltage disable and coolant-service boundary.

P2602 Causes and the Evidence That Separates Them

The strongest P2602 diagnosis explains the code definition, the captured operating conditions, and any companion codes with one testable fault path. The physical pump and loop must be identified before any fuse, connector or temperature conclusion is useful.

1

Shorted Control Wire

Rub-through or coolant intrusion can pull a commanded circuit low.

How to prove it: Isolate the branch and use the approved loaded circuit test without backfeeding the module.

Check first
2

Missing Pump Power Feed

A fuse, relay, splice or high-resistance terminal can remove supply.

How to prove it: Check voltage at the pump under command and inspect shared-device faults before replacing a fuse.

Check first
3

Weak Ground or Connector

Corrosion, loose fit or heat damage can collapse voltage under load.

How to prove it: Measure voltage drop across the actual power and ground paths while the pump is requested.

Verify directly
4

Pump Motor or Smart Electronics Fault

A shorted winding or failed internal controller can overload the output.

How to prove it: Compare commanded current/feedback to OEM limits after wiring and coolant safety checks.

Verify directly
5

Controller Driver Protection or Fault

A driver may shut down in response to an external overcurrent.

How to prove it: Prove load, harness, powers and grounds before any controller service.

Verify directly
6

Separate Flow or Cooling Fault

Air, low coolant, restriction or thermostat problems may coexist but are not the circuit-low definition.

How to prove it: Resolve the electrical path, then evaluate flow and thermal performance if data remains abnormal.

Final branch

Cause lists are starting points. If a fuse opened, find the overcurrent source and every load on that fuse before restoring power. Test the circuit in its failed state when possible, document the result, and replace a part only after the measured evidence points to it.

Using UR1000 to Organize P2602 Evidence

The iCARZONE UR1000 Bidirectional Scan Tool with ECU Coding supports full-system diagnostics, available DTCs, freeze frame, ECU information and live data. For P2602, use those records to compare pump command, speed or feedback with loop temperatures, fan command, system voltage and related module faults, while keeping the first-failure order intact.

The official product page advertises bidirectional control and ECU coding. Coverage varies by VIN, ECU and software. Do not assume a menu item can command coolant pump A; active tests and parameter names are vehicle-specific, and a supported command is not proof that the connected component can physically respond.

Work cold and depressurized. Smart pumps can start automatically. Use approved backprobes, fused test leads and load methods; never bypass a controller output. Treat orange cables and high-voltage cooling components as restricted unless qualified.

RECOMMENDED DIAGNOSTIC TOOL

iCARZONE UR1000 Bidirectional Scan Tool with ECU Coding

iCARZONE UR1000 diagnostic scan tool
Full-system scan · freeze frame · supported live data

Use UR1000 to preserve pump command/feedback, loop temperatures, voltage, fan state, warnings and companion-module faults, then follow the VIN-specific electrical and mechanical tests before authorizing parts.

$329.99
$349.99
Check UR1000 Coverage

Price and availability checked September 3, 2026. Prices shown are USD. Recheck the current offer, stock and required vehicle/function coverage before purchase.

How to Diagnose P2602 in 6 Evidence-Based Steps

Use this order to avoid erasing the event or chasing a plausible part without proof. Start with loop identity because several vehicles have multiple electrically driven coolant pumps. A failed test should lead to the next branch in the OEM procedure; a passed test should narrow the search rather than trigger replacement.

P2602 Quick Diagnostic Path

  • 1

    Make the System Safe and Save Data

    • Stop for thermal or high-voltage warnings; allow cooling and record every module.
    • Capture temperatures, pump command/feedback, voltage, fan state and first-failure order.
  • 2

    Identify Pump A and Its Loop

    • Use the VIN service information to locate the exact pump, controller and coolant circuit.
    • Confirm high-voltage restrictions, automatic-start behavior, fuse/relay and shared paths.
  • 3

    Inspect Cold External Hardware

    • With the system safe, inspect coolant leaks, connector seals, routing, corrosion and grounds.
    • Do not open the system or reach near automatic fans while hot.
  • 4

    Load-Test Power and Ground

    • Command the pump only if supported and safe, then measure supply and ground voltage drop.
    • A static 12-volt reading without load does not prove the circuit can carry current.
  • 5

    Test Control and Pump Load

    • Follow the specified control-signal, current or communication test and isolate the pump as directed.
    • Do not jumper a smart pump or controller output unless the OEM procedure supplies a protected method.
  • 6

    Repair and Verify Thermal Response

    • Correct the proven circuit, pump or supply fault, then refill and bleed by specification if opened.
    • Confirm command/feedback, temperature response, fan strategy and monitor completion without return.
Coolant can be hot and pressurized, pumps and fans can start automatically, and electrified-vehicle loops can cross high-voltage service boundaries. Use PPE, lockout steps and qualified support exactly as the OEM procedure requires.

How to Fix P2602 and Verify the Repair

01

Repair Wiring or Connector

Restore the proven short, terminal, seal, ground or harness routing with the correct environmental protection.

02

Restore the Supply Path

Repair a fuse, relay, splice or feed only after the underlying overload or resistance is identified.

03

Replace the Proven Pump

Install the correct pump or module when loaded circuit and internal tests support failure.

04

Correct Remaining Cooling Faults

After electrical control is restored, repair verified leaks, air, restrictions or flow problems separately.

01

Electrical and Thermal Diagnosis

VIN-specific quote
Main cost driver

Loop identification and safe command testing often account for most initial labor.

02

Harness, Relay, or Connector Repair

VIN-specific quote
Main cost driver

Cost depends on access, environmental damage and shared-circuit scope.

03

Pump Replacement

VIN-specific quote
Main cost driver

Pump integration, coolant service and bleeding requirements vary widely.

04

Electrified-System Service

VIN-specific quote
Main cost driver

High-voltage qualification, isolation and special coolant procedures can add significant labor.

A completed repair should correct the proven fault and preserve the original evidence in the work record. Verify normal loaded voltage, pump command/feedback, leak-free coolant level, correct bleed, expected temperature change and no returning thermal or circuit faults.

Clear codes only after the repair and baseline checks are complete. Run the specified monitor or road-test conditions, rescan every relevant module, and compare the post-repair data with the saved event. A code that does not return during a short idle period is not automatically a verified fix.

P2602 OEM Differences and DIY Limits

Pump A may serve the engine, turbocharger, inverter, battery, charge-air cooler or another thermal circuit depending on the vehicle. That is why the displayed OEM description, wiring diagram, component locator, terminal identification, test conditions, and service bulletin applicability must match the full VIN.

Architecture Question

Which physical pump and coolant loop does the OEM designate A?

Definition Boundary

Is the output relay, PWM, smart communication, low-side or high-side controlled?

Repair Boundary

Does the loop cross a high-voltage, vacuum-fill, bleed or automatic-start boundary?

Some pumps use simple motor control; others contain electronics and communicate with a controller. Generic guidance can organize evidence, but it must stop before unverified terminal probing, module programming, high-energy work, or disassembly that requires special tools and cleanliness controls.

Reasonable DIY Checks
  • Record all modules, freeze frame and first-failure order before clearing.
  • Inspect a cold accessible connector, harness and coolant level only within your training.
  • Inspect accessible connectors and harness routing with power off.
  • Use the correct wiring diagram and approved probes for any measurement.
Professional-Level Work
  • Do not open hot coolant systems or enter high-voltage service areas.
  • Do not pierce sealed wiring or spread terminals to obtain a reading.
  • Do not run unsupported active tests or programming routines.
  • Escalate when the procedure requires special tooling, disassembly, or controlled hazards.

Related Thermal, Voltage, and Sensor Guides

Companion codes can change the test order for P2602. Review these verified iCARZONE guides for nearby monitor families, but use the exact vehicle service information to decide whether they share a feed, ground, sensor, controller, or physical system.

For other stored faults, use the iCARZONE OBD-II fault-code center.

Frequently Asked Questions About P2602

Does P2602 mean coolant pressure or flow is low?
No. It means the pump A control circuit is electrically low. Flow and temperature require separate evidence.
Does P2602 prove the pump is bad?
No. Feed, ground, connector, wiring, relay, driver or smart-pump electronics can create the code.
Which pump is coolant pump A?
The assignment varies. Use VIN service information because a vehicle may have several coolant loops and pumps.
Can I drive with P2602?
Stop for thermal or high-voltage warnings, steam, coolant loss or escalating reduced power. Follow OEM guidance otherwise.
Can UR1000 command the pump?
Bidirectional support is advertised, but exact pump tests vary by VIN, ECU and software. Verify coverage and safety.
Can I jumper the pump to test it?
Not without an OEM-approved protected method. Smart electronics or module drivers can be damaged.
Do I need to bleed the system after repair?
If the loop is opened, use the specified coolant and bleeding or vacuum-fill procedure for that exact loop.
How is repair verified?
Confirm loaded circuit behavior, supported pump response, normal temperatures, correct coolant level and monitor completion.
