P2813 Code: Pressure Control Solenoid G Range/Performance

Performance



STOP — SEVERE SLIP, OVERHEAT, OR LOSS OF DRIVE? ARRANGE A TOW

P2813 Code: Test the Command-to-Pressure Relationship First

Save the transmission event, identify the exact solenoid G circuit, compare command with response, and prove whether the fault is electrical, hydraulic, or internal before buying parts.

Updated August 12, 2026About 15 min readReviewed by iCARZONE Tech Team
QUICK ANSWER

P2813 means Pressure Control Solenoid G Control Circuit Range/Performance. It does not automatically prove the solenoid is bad. The TCM found that the command, current, or resulting hydraulic behavior was outside its expected relationship. Save all module codes and freeze frame, identify the exact transmission, verify fluid and supply voltage, graph relevant TCM data, and then test the circuit or hydraulic branch. On supported vehicles, UR1000 can preserve the record, access enhanced transmission data, and run available active tests; direct electrical and pressure proof still requires the correct service information and test equipment.

What P2813 Pressure Control Solenoid G Range/Performance Means

P2813 is a generic powertrain DTC with the standard description Pressure Control Solenoid G Control Circuit Range/Performance. Automatic, continuously variable, and dual-clutch transmissions use electronically controlled valves to regulate pressure for clutches, pulleys, lubrication, cooling, or a manufacturer-defined hydraulic circuit. The letter G distinguishes one monitored control path; it does not describe a universal location.

The controller may compare command, current, pressure, speeds, ratio, temperature, and learned behavior. P2813 sets when these values disagree under its enable conditions. The command may be distorted, the valve may stick, or the hydraulic result may not follow.

Range/performance is a relationship fault. A coil may pass cold yet a valve stick hot; wiring may fail with vibration; and valve-body or internal leakage can make a correct command ineffective.

Stop driving for severe slipping, loss of forward or reverse drive, a transmission overheat warning, burning odor, major fluid leakage, violent engagement, or loud mechanical noise. Continued operation can turn a diagnosable control fault into clutch, belt, or hard-part damage.

If P2813 is only history, avoid heavy use until the record is reviewed. Do not erase the original status and freeze frame first.

P2813 Symptoms and Severity

Severity ranges from a silent history code to serious slip. Note temperature, gear, load, and whether the fault began after battery work, fluid service, or transmission repair.

Check Engine or Transmission Warning
A generic reader may show only P0700, so scan every module before clearing anything.
Harsh or Delayed Engagement
Drive, reverse, or a shift may engage late or unusually firmly.
Slipping or RPM Flare
RPM rises without matching acceleration. Stop driving if slip is severe.
Fail-Safe Operation
The controller may hold a fixed ratio or restrict torque.
Shudder or Poor Acceleration
Pressure-control trouble can disturb clutch application, but internal wear can feel similar.
No Obvious Symptom
An intermittent connector, cold-start, or low-voltage event may leave only a history code.

Common P2813 Causes in Test Order

Start with evidence, fluid, voltage, and accessible connectors. Companion voltage, ratio, temperature, sensor, or communication codes can change the order.

1

Low, Incorrect, Degraded, or Aerated Fluid

Fluid level, specification, or condition can distort hydraulic response.

How to prove it: Follow the exact level procedure and inspect for leaks, odor, foam, or debris.

Check first
2

Connector, Harness, Power, or Ground Fault

Corrosion, fluid intrusion, chafing, high resistance, or voltage loss can distort solenoid current.

How to prove it: Inspect external and case connectors, then test the circuit in the correct state.

Check first
3

Solenoid G Electrical or Mechanical Fault

The coil can fail electrically or the valve can stick from wear or contamination.

How to prove it: Compare command, current or duty cycle, and response; then run the specified de-energized test.

Test directly
4

Valve Body or Hydraulic Leakage

A worn bore, damaged gasket, restricted passage, or cross-leak can prevent the expected pressure change.

How to prove it: Confirm electrical control, inspect fluid and the pan, then follow the OEM hydraulic test.

Test directly
5

Pump, Clutch, Belt, or Internal Wear

Pressure loss, clutch leakage, CVT belt slip, or debris can mimic a solenoid fault.

How to prove it: Correlate pressure, ratio, speeds, slip data, and debris before internal work.

Advanced branch
6

Calibration, Adaptation, or Rare TCM Fault

Some vehicles require a calibration or learned-value procedure; controller failure is less common.

How to prove it: Check VIN-specific bulletins after fluid, power, wiring, and mechanical response pass.

Advanced branch

The Key Split: Did the Command Change and Did the Transmission Respond?

Ask three questions: did the TCM command a change, did the circuit carry it, and did pressure, ratio, or clutch behavior respond? Graph only the useful PIDs and mark the symptom.

Original diagnostic map: command, circuit, response

P2813 command-to-response diagnostic map A five-stage path from the TCM command through the electrical circuit and solenoid to the hydraulic result and vehicle response. TCM COMMANDduty cycle / current CIRCUITpower / wire / ground SOLENOID Gcoil + moving valve HYDRAULIC RESULTpressure / ratio / clutch slip P2813 SETSrelationship is implausiblePROVE THE FAILED BRANCHelectrical / hydraulic / internal
The code reports a failed relationship. Test each link instead of assuming the box labeled solenoid G is defective.
Useful graph: command or current, available pressure feedback, input speed, output speed, calculated ratio, slip, selected gear, and fluid temperature. Use only PIDs supported by the exact TCM.

Using UR1000 for P2813 Diagnosis

The iCARZONE UR1000 can access supported transmission controllers, save code status and freeze frame, graph live data, show ECU information, and create reports. A basic emissions reader may show only P0700 without detailed TCM evidence.

Compatible modules may offer active solenoid or pressure-control tests. Availability is vehicle-specific: confirm enhanced PIDs, tests, coding, and adaptations by VIN.

UR1000 does not directly measure pressure, resistance, continuity, voltage drop, or leakage. Physical proof still needs the correct meter, pressure equipment, and service procedure.

RECOMMENDED DIAGNOSTIC TOOL

iCARZONE UR1000 Bidirectional Scan Tool with ECU Coding

Full-system scan · live-data graphs · supported active tests · lifetime Wi-Fi updates

Use UR1000 to save the P2813 event, scan companion modules, compare supported command and response data, and document the verification drive. Confirm enhanced transmission coverage by VIN.

$329.99
$349.99
Check UR1000 Coverage
Coverage note: transmission PIDs, output tests, relearns, coding, and service functions vary by make, model, year, transmission, ECU, and configuration. Check the exact function before purchase or repair.

How to Diagnose P2813 in 6 Steps

Use this framework with the exact factory test. Never substitute universal fluid, resistance, current, pressure, or road-test values.

  • 1

    Confirm Severity and Preserve the Original Event

    • Stop driving for severe slip, loss of drive, burning odor, overheat warning, major fluid loss, or repeated harsh engagement.
    • Record whether it occurs cold, hot, after service, during a shift, or under load.
    • Do not disconnect the battery or clear codes before saving the complete record.
  • 2

    Run a Full-System Scan and Identify the Transmission

    • Use UR1000 to scan the transmission, engine, ABS, and related modules, then save P2813, status, freeze frame, and companion codes.
    • Identify the transmission family, calibration, and manufacturer name for solenoid G.
    • Do not assume the letter G identifies the same physical valve, clutch, or pressure circuit on every vehicle.
  • 3

    Inspect Fluid, Leaks, Connectors, and Supply Voltage

    • Check fluid only by the OEM procedure; many sealed units require a defined temperature and engine state.
    • Inspect the external harness, case connector, grounds, fuses, and evidence of water, oil, impact, or prior repair.
    • Correct unstable battery or charging voltage before judging TCM commands or programming.
  • 4

    Graph Command, Current, Pressure, Ratio, and Speed Data

    • Graph only relevant PIDs: command, current, pressure, ratio, speeds, slip, and temperature.
    • Reproduce the event safely while comparing the command change with the hydraulic and mechanical response.
    • Treat a missing PID as a coverage limitation, not proof that the vehicle lacks the monitored function.
  • 5

    Prove the Electrical or Hydraulic Branch

    • With power removed, perform only the specified coil, continuity, short-to-power, short-to-ground, and terminal-load tests.
    • If the circuit passes but response is wrong, continue with the approved hydraulic procedure.
    • Never apply battery voltage directly to an unknown low-current TCM driver or solenoid.
  • 6

    Repair, Initialize, and Verify Under Enable Conditions

    • Repair only the proven fluid, wiring, solenoid, valve-body, internal, calibration, or controller branch.
    • Complete required fluid filling, adaptation, relearn, coding, or initialization with stable support voltage.
    • Clear eligible codes, repeat the monitor, and confirm no pending P2813 or companion fault.

P2813 Decision Tree: Electrical, Hydraulic, or Internal?

Original decision tree: choose the next test

P2813 decision tree A decision tree that checks severe symptoms, then circuit control, then hydraulic response to identify the repair branch. P2813 + EVENT SAVEDidentify exact transmission SEVERE SLIP, OVERHEAT,OR LOSS OF DRIVE? YESSTOP + TOWprevent more damage NOCIRCUIT PASSES?command + wire + coil NOELECTRICALconnector / wire / coil / TCM YESHYDRAULIC / INTERNALvalve body / pressure / clutch
An electrical pass does not prove the whole transmission is good; it simply moves diagnosis to hydraulic response and internal integrity.

How to Fix and Clear P2813 Safely

Fluid or leak: use the specified fluid and level procedure, repair the source, and avoid unsupported flushing.

Circuit: repair terminals or wiring with sealed methods and restore harness routing. Appearance alone does not replace a loaded test.

Solenoid or valve body: confirm serviceability, cleanliness, bolt, seal, fill, and initialization procedures before opening the unit.

Internal damage: metal, clutch debris, ratio errors, low pressure, or persistent slip can justify deeper inspection. One code alone does not.

Clear and Verify P2813

  1. Save the original DTC status, freeze frame, scan report, fluid findings, and graph.
  2. Complete the proven repair plus required filling, coding, adaptation, or relearn.
  3. Clear eligible codes with UR1000 and confirm normal module communication.
  4. Repeat the correct enable conditions safely; rescan for pending P2813 and companion codes.

Do not use battery disconnection as the first reset. It can erase learned values and diagnostic evidence without repairing the cause.

P2813 Diagnostic and Repair Cost Factors

These broad U.S. planning ranges are not quotes; access, fluid, programming, damage, and labor vary.

Repair Branch Broad Planning Range Required Evidence
Scan, graphing, and diagnosis $120–$400 Saved event, reproduction, circuit or pressure result
External connector or wiring $120–$750+ Failure under the correct state, load, or temperature
Fluid, filter, leak, and service $180–$650+ Verified level, specification, condition, or leakage issue
Solenoid, internal harness, or valve body $450–$2,800+ Electrical pass/fail plus hydraulic response and serviceability
Internal CVT/automatic repair $2,500–$8,000+ Slip, debris, ratio, pressure, and internal inspection evidence

Before authorizing programming, a valve body, or a transmission, check warranty coverage, recalls, campaigns, and VIN-specific technical bulletins.

Where P2813 Diagnosis Differs by Vehicle

The definition is shared, but the monitored function is not. Some Nissan CVTs call it a select solenoid; other units use G and may require an internal harness or control valve.

Application Pattern Verify First Why It Matters
Nissan CVT applications Transmission model, TCM codes, judder/slip evidence, calibration Nissan bulletins pair P2813 with other CVT codes and route repair by belt-slip and control-valve evidence.
Conventional stepped automatic OEM solenoid map, commanded gear, clutch application Letter G may control a specific clutch or pressure branch, and access varies.
Integrated mechatronic unit Internal harness, valve body serviceability, programming The solenoid may not be a separately replaceable external part.
After transmission replacement Hardware match, QR/strategy data, coding, relearn A mismatched or uninitialized control unit can imitate a hardware failure.

DIY Limits and When to Use a Professional

Reasonable DIY Checks
  • Save all module codes and freeze frame with UR1000.
  • Identify the transmission and exact OEM code wording.
  • Inspect accessible wiring, connectors, leaks, and fluid history.
  • Graph supported command and response data.
!Professional-Level Work
  • Loaded TCM-driver and scope diagnosis.
  • Running hydraulic pressure tests.
  • Pan, valve-body, mechatronic, CVT, or internal work.
  • Programming, coding, and manufacturer relearns.

Choose professional diagnosis now for severe slip, loss of drive, overheating, burning odor, visible metal or clutch debris, high-voltage hybrid components, or any test that requires a running raised vehicle.

Seven Related iCARZONE Transmission-Code Guides

Use these internal guides to compare pressure-control, shift-solenoid, speed-sensor, range-sensor, MIL-request, and TCM-communication evidence.

Frequently Asked Questions About P2813

What does P2813 mean?
P2813 means Pressure Control Solenoid G Control Circuit Range/Performance. The controller detected that the command, current, or resulting transmission response did not behave within the programmed range.
Is P2813 always a failed solenoid?
No. Fluid condition, a connector, external or internal wiring, valve-body leakage, pressure supply, clutch or CVT damage, calibration, and rare TCM faults can produce the same code.
Can I drive with P2813?
Avoid normal driving until severity is known. Stop and tow for severe slip, loss of drive, overheating, burning odor, major leakage, or violent engagement. A mild isolated event still needs prompt diagnosis.
Can UR1000 diagnose P2813?
On supported vehicles, UR1000 can access the TCM, save codes and freeze frame, graph live data, create reports, and run supported active tests. Coverage varies, and meters or pressure equipment may still be required.
Will changing transmission fluid fix P2813?
Only when level, specification, degradation, aeration, or contamination is the verified cause and the unit is serviceable. Fluid service cannot repair damaged wiring, a worn valve body, or internal clutch and belt damage.
How do I clear P2813 safely?
Save the original evidence, repair the proven cause, complete required filling and relearn procedures, then clear eligible codes and repeat the manufacturer enable conditions. Battery disconnection is not a repair.

Sources and Technical Review Notes

Generic wording was cross-checked against current DTC references, while vehicle-specific cautions use manufacturer service bulletins hosted by NHTSA.

  • Nissan NTB20-091A hosted by NHTSA — lists P2813 with specific CVT companion codes and routes repair using judder and belt-slip evidence rather than automatic solenoid replacement.
  • Nissan NTB16-110k hosted by NHTSA — includes P2813 in an Altima CVT repair flow and shows why exact vehicle, transmission, calibration, and service procedure matter.
Bottom Line: P2813 describes a command-to-response problem in the pressure control solenoid G path. Preserve the event, identify the exact transmission, verify fluid and electrical supply, graph the smallest useful TCM data set, and prove the electrical or hydraulic branch. UR1000 can organize supported module evidence and tests; meters, pressure equipment, and factory procedures complete the diagnosis.
